PalletPal Mobile Leveler / Portable Lift

PDF CATALOG

TYPE: Pallet Handling

MODEL: PalletPal Lift Truck

The PalletPal Mobile Leveler provides multi-use functionality as a mobile lift table, mobile pallet lift, mobile pallet positioner or as a companion to other PalletPal Levelers. It can deliver and remove loads quickly and easily without the expense of a ride-on fork truck. The straddle design accepts any pallet or skid. It transports items effortlessly, is less expensive than a ride on forklift and doesn't require special training or certifications for use.

Features

More economical than a ride on forklift
No certifications or training to use
Up to 3000 lb capacity
Extra rugged construction
Low mast for improved visibility
Adjustable height and portability in a single machine
Available in fork over or straddle styles
Use with any type of pallet or skid, even closed bottoms
Dual wheel steering provides unmatched maneuvering
Built in battery charger (internal battery charger and battery discharge indicator
Ergonomic contoured handle and grouped controls
Locking hand brake

Options

Fork over design for open bottomed pallets and skids
Straddle design accommodates any pallet style including closed bottom
Automatic Load Leveling Eye

Applications

Can be used as a:

Mobile lift table
Mobile pallet lift
Mobile pallet positioner
or as a Feed Unit with other PalletPal levelers

Specifications

Model	Capacity	Raised Height	Lowered Height	Load Center	Fork Width	Power	Shipping Weight
PML-30-ME Fork Over	3000 lbs	36"	3.25"	24"	22"	12 V DC	510 lbs
PMLS-30-ME Straddle	3000 lbs	35"	2.25"	24"	14" - 31"	12 V DC	730 lbs

For more information on the Southworth PalletPal Mobile Leveler, please contact a Thomas Conveyor & Equipment Ergonomic Automation Engineer at 844 220 0086 or click on the Contact Us button above.
