Wexxar BEL 270 Hot Melt Glue Case Sealer

The BEL 270 is an automatic uniform hot melt glue case sealer.  Its compact size, quality construction and safe operating performance makes it unmatched in the industry when compared to other units.
PDF CATALOG

TYPE: Hot Melt Glue Sealers

MODEL: Wexxar BEL 270

The BEL 270 is an automatic uniform hot melt glue case sealer. Its compact size, quality construction and safe operating performance makes it unmatched in the industry when compared to other units.

The sealer is user friendly and simple to operate - case size changes can be completed from either side of the machine in less than a minute! It can be fitted with all popular brands of hot melt glue applications, and its unique static compression system allows for quick, uniform bonding of the adhesive for positive case sealing at speeds of up to 25 cases per minute.

Eco Friendly Application


Features

  • Size:- Compact machine footprint (only 58") for applications with limited floor space
  • Snap Folder System for safe reliable top flap folding; new design eliminates traditional "flap kicker" which can cause injury
  • Case size changes can be completed from either size of the machine in under one minute using two hand wheel adjustments
  • Accommodates many different case sizes and pack configurations
  • Unit can be fitted with all popular brands of hot melt glue application systems
  • Centralized, color-coded setup guides make case changeovers quick and easy
  • The Uni-Drive Belt System eliminates case skew and ensures that cases are squarely taped
  • Its unique static compression system provides quick uniform bonding of adhesive for positive case sealing
  • Speeds of up to 25 cases per minute
  • System seals cases with a gap free top closure on regular RSC cases which provides superior dust and light blockage
  • Allows for manual inspection of the products
  • Quick and easy maintenance
  • Designed and built in North America with premium materials

Applications

  • Automotive / Hardware
  • Bakery
  • Beverage
  • Confectionery/Snacks
  • Dairy
  • Furniture / Household Goods / Electronics
  • Meat / Seafood
  • Retail Ready
  • Personal Care / Cosmetics
  • Pharmaceutical / Medical
  • Produce / Agriculture
  • Textiles/Apparel

Specifications

  • Speed: up to 35 cases per minute (CPM)
  • Corrosion resistant and paint free frame construction
  • Machine Weight: 650 lbs
  • Machine Dimensions: 56”(L) x 33”(W) x 60”(H)
  • Electrical: 120 Volts, 1 PH, 60 Hz - 8 amp draw
  • Case Size Minimum : 8" x 6.5" x 6.25" (Top Seal Only)
  • Case Size Maximum : 20" x 15" x 15"  (Top Seal Only)
  • Case Size Minimum : 8" x 8.5" x 5.25" (Top/Bottom Seal)
  • Case Size Maximum : 16" x 15" x 14.25"  (Top/Bottom Seal)
  • Infeed/Outfeed Height Minimum :  20.5" Top Only
                                                     21.75" Top & Bottom
  • Infeed/Outfeed Height Maximum : 28.75" Top Only
                                                     30" Top & Bottom

Options

  • The BEL 270 can be configured to run lower cost Gap Flap style, as well as FOL-bag in box style cases
  • Adjustable Box Stand
  • A-42 Rotary Accumulation Turntable
  • Modifications for undersized or oversized cases
  • Total Lock Caster Wheels with Extension Adjustment
  • Roller Conveyor for Infeed & Outfeed
  • Flexible Conveyor
  • Spare Parts Kits for Machine Maintenance
  • S-10 Packing Conveyor with Programmable Weigh Scale
  • Ergo Level Packing Height Adjustment Option
  • Stainless Steel/Enviroguard Washdown Unit Available
  • Gap Flap or other case style modifications
  • Custom Guarding
  • Digital Dial Indicators
  • Separate Disconnect for Hot Melt

For more information on the Wexxar BEL 270 Automatic Hot Melt Glue Case Sealerplease contact a Thomas Conveyor & Equipment Automation Engineer at 844 220 0086 or click on the Contact Us button above.
